Egripment Super Javelin MK II

The Super Javelin MK II is an ultra modern crane system with a partially “open” design structure that is being extended with a modern tubing section. The parallel bars are integrated inside the arm of the Javelin which causes less shadows and makes it easier to get into difficult to reach spots on sets. Super Javelin MK II offers a very stable remote crane at heights up to 40 ft/12,2 mtrs.
BROCHURE FOR SUPER JAVELIN MK II:
Description
The Super Javelin MK II is an ultra modern crane system with a partially “open” design structure that is being extended with a modern tubing section. The parallel bars are integrated inside the arm of the Javelin which causes less shadows and makes it easier to get into difficult to reach spots on sets. Super Javelin MK II offers a very stable remote crane at heights up to 40 ft/12,2 mtrs. The modular systems offers you eight different sizes and can be configurated to handle weight ranging from 220 lbs/100 kgs at 7.8 mtrs/25 ft to 88 lbs/40 kgs at 40 ft/12,2 mtrs. Existing Javelin cranes can also be easily upgraded to the super Javelin MK II. The Javelin is mounted on a wide base dolly. The dolly has four wheel steering and can be operated from the front or the back.
BROCHURE FOR SUPER JAVELIN MK II:
Specifications
SVJ01
Type: | remote |
Arm reach: | 540 cm |
Operational length : | 780 cm |
Maximum height: | 610 cm |
Minimum height: | -50 cm |
Maximum load: | 65 kg |
JAVELIN DOLLY SPECIFICATIONS
Type: | widebase dolly |
Width: | 125 cm |
Length : | 165 cm |
Height: | 198 cm |
Weight: | 185 kg |
Type of wheels: | hard rubber – track – pneumatic |
SVJ02
Type: | remote |
Arm reach: | 690 cm |
Operational length : | 930 cm |
Maximum height: | 730 cm |
Minimum height: | -125 cm |
Maximum load: | 65 kg |
JAVELIN DOLLY SPECIFICATIONS
Type: | widebase dolly |
Width: | 125 cm |
Length : | 165 cm |
Height: | 198 cm |
Weight: | 185 kg |
Type of wheels: | hard rubber – track – pneumatic |
SVJ03
Type: | remote |
Arm reach: | 740 cm |
Operational length : | 980 cm |
Maximum height: | 770 cm |
Minimum height: | -150 cm |
Maximum load: | 65 kg |
JAVELIN DOLLY SPECIFICATIONS
Type: | widebase dolly |
Width: | 125 cm |
Length : | 165 cm |
Height: | 198 cm |
Weight: | 185 kg |
Type of wheels: | hard rubber – track – pneumatic |
SVJ04
Type: | remote |
Arm reach: | 790 cm |
Operational length : | 1030 cm |
Maximum height: | 810 cm |
Minimum height: | -175 cm |
Maximum load: | 65 kg |
JAVELIN DOLLY SPECIFICATIONS
Type: | widebase dolly |
Width: | 125 cm |
Length : | 165 cm |
Height: | 198 cm |
Weight: | 185 kg |
Type of wheels: | hard rubber – track – pneumatic |
SVJ05
Type: | remote |
Arm reach: | 890 cm |
Operational length : | 1130 cm |
Maximum height: | 890 cm |
Minimum height: | -225 cm |
Maximum load: | 65 kg |
JAVELIN DOLLY SPECIFICATIONS
Type: | widebase dolly |
Width: | 125 cm |
Length : | 165 cm |
Height: | 198 cm |
Weight: | 185 kg |
Type of wheels: | hard rubber – track – pneumatic |
SVJ06
Type: | remote |
Arm reach: | 940 cm |
Operational length : | 1180 cm |
Maximum height: | 935 cm |
Minimum height: | -250 cm |
Maximum load: | 65 kg |
JAVELIN DOLLY SPECIFICATIONS
Type: | widebase dolly |
Width: | 125 cm |
Length : | 165 cm |
Height: | 198 cm |
Weight: | 185 kg |
Type of wheels: | hard rubber – track – pneumatic |
SVJ07
Type: | remote |
Arm reach: | 990 cm |
Operational length : | 1230 cm |
Maximum height: | 975 cm |
Minimum height: | -275 cm |
Maximum load: | 65 kg |
JAVELIN DOLLY SPECIFICATIONS
Type: | widebase dolly |
Width: | 125 cm |
Length : | 165 cm |
Height: | 198 cm |
Weight: | 185 kg |
Type of wheels: | hard rubber – track – pneumatic |
SVJ08
Type: | remote |
Arm reach: | 1140 cm |
Operational length : | 1380 cm |
Maximum height: | 1100 cm |
Minimum height: | -350 cm |
Maximum load: | 40 kg |
JAVELIN DOLLY SPECIFICATIONS
Type: | widebase dolly |
Width: | 125 cm |
Length : | 165 cm |
Height: | 198 cm |
Weight: | 185 kg |
Type of wheels: | hard rubber – track – pneumatic |
