Atlas Lens-Orion Series A Set 40/65/100
Key Features
- 2x Anamorphic Design: Produces classic oval bokeh, streak flares, and widescreen cinematic imagery
- Includes 40mm, 65mm, and 100mm: Versatile focal range for portraiture, medium shots, and telephoto work
- Fast T2 Aperture: Delivers excellent low-light performance and beautiful background separation
- Matched Cine Housings: Consistent focus and iris gear placement, 114mm front diameters
- Super 35 Coverage: Ideal for ARRI Alexa Mini, RED Komodo/V-RAPTOR (S35 mode), Canon C300, etc.
- Professional Build: All-metal construction with precision mechanics for rugged production use
Description
Atlas Lens – Orion Series A Set (40mm / 65mm / 100mm Anamorphic Primes)
The Atlas Orion Series A Set includes the original core focal lengths — 40mm, 65mm, and 100mm — from the Orion Series, Atlas Lens Co.’s flagship line of 2x anamorphic cinema lenses. Designed for Super 35 sensor coverage, these lenses deliver the beloved characteristics of vintage anamorphic glass: expansive horizontal field of view, rich oval bokeh, cinematic flares, and a painterly depth of field — all housed in robust, production-ready barrels.
With a consistent T2 aperture, unified lens design, and professional build quality, this set is ideal for cinematographers, DPs, and filmmaking professionals seeking a high-performance anamorphic solution.
A UNIVERSAL FILMMAKING TOOL
Orion Series lenses are convenient, adaptable, dependable, and ergonomic, with the best of both vintage and modern features.
Orion Series lenses are readily and easily compatible with all mirrorless video / stills hybrid cameras via any PL to mirrorless camera adapter.
Whether your project requires you to shoot digital or film, the Orion Series offer the coverage you need with a 24.89mmx18.66mm imaging area and easily covers full frame formats edge-to-edge with the Atlas LF Extender.
- Interchangeable Mount System with native PL or EF mount options
- Works with E-mount or Micro 4/3 camera with appropriate adapters
- Covers full-frame (FF), large format (LF) or Vistavision with our 1.6x LF Extender
- Focus has a deep 270° travel rotation
- Cine pitch 0.8 mod gearing on both iris and focus ring allow for simultaneous drive control, even when two motors are mounted on the same side of the lens
Vintage anamorphic characteristics- |
Modern conveniences- |
 Waterfall bokeh |
 Crisp flat-field performance when stopped down to a T2.8 or deeper |
 Streak flare |
 Fast T2 aperture |
 Disproportionate perspective magnification (Telephoto lens with wide-angle field) |
 Modern, mechanically dependable design (standardized across all 6 focal lengths) |
 Pleasant spherical aberration glow when wide open |
 Unified focus and iris position (reduces need for adjustment when switching to different focal lengths) |
 Pleasing barrel distortion |
 Standardized 114mm outer diameter for native use with a variety of matteboxes and filters |
Technical Specifications:
| Orion Series | 32mm | 40mm | 50mm | 65mm | 80mm | 100mm |
| T-Stop Range | T2 – T16 | T2 – T16 | T2 – T16 | T2 – T16 | T2 – T16 | T2 – T16 |
| Min Focus (FT) | 1.75 FT | 2 FT | 2.5 FT | 2.75 FT | 3 FT | 3.5 FT |
| Min Focus (M) | .53 M | .53 M | .76 M | .84 M | .91 M | 1 M |
| Weight (LBS) | 4.7 LBS | 5.2 LBS | 5 LBS | 5 LBS | 6 LBS | 6.7 LBS |
| Weight (KG) | 2.1 KG | 2.4 KG | 2.3 KG | 2.2 KG | 2.7 KG | 3 KG |
| Length (IN) | 6.7” | 7.4” | 7” | 7.2” | 8.5” | 10” |
| Length (CM) | 17 cm | 18.9 cm | 17.8 cm | 18.4 cm | 21.5 cm | 25.4 cm |
| Front Diameter (MM) | 114 mm | 114 mm | 114 mm | 114 mm | 114 mm | 114 mm |
| Image Circle | 31 mm | 31 mm | 31 mm | 31 mm | 31 mm | 31 mm |
